360 Patterns Digital Multi Needle Quilting Machine 3800kg 3 Phase

Basic Information
Place of Origin: CHINA
Brand Name: ZOLYTECH
Certification: CE
Model Number: YS 128-3
Minimum Order Quantity: 1pcs
Price: USD 20000-30000 PCS
Packaging Details: WOODEN BOX
Delivery Time: 30 DAYS
Supply Ability: 30 PCS/ MONTH
Detail Information
Details: YS 128-3 Dimension ( L X W X H )mm: 5560*1370*1780MM
Voltage: 380 V/ 50hz 220v/60hz,3-phase Total Power Required: 5.5kw
Main Shaft Speed: 300-800 Rpm Model Of Needle: 14-21#
Speed Of Production: 60-100m/hour Stitch Length: 2-7mm
Quilting Width: 3300mm Space Between Needle Bars: 76.2,152.5
Gross Weight: 3800kg Thickness Of Quilting: 30mm
High Light:

Multi Needle Quilting Machine 3800kg

,

digital quilting machine 3800kg

,

360 Patterns Multi Needle Quilting Machine


Product Description

Computerized Lock Stitch Multi Needle Quilting Machine For Quilt



Purpose:It is widely used for quilting high-quality garments, quilt covers,hand bags , gloves,sleeping bags,pajamas,bed spreads,seat covers,plus material and household ornaments.



Advantages:



Material rack separation structure ,can reduce the load of the rack effectively.



Multi-span independent pattern (360°and 180° patterns are available)



New generation of CNC system,advanced machine structure,high precision quilting,dispense with too much parameter adjustment or pattern modification during quilting.



Different patterns in each line can be quilted on 3.2m fabric and patterns can strongly combine.





Extreme precision with 360 intricated patterns including bartack and jump patterns with automatic

top thread cut.



> Independent positive presser foot system,with wide possibilities of adjusting stroke and

passage clearance, Capable of compressing thin or very thick filling materials(up to 80mm)





Technical parameters:



model  YS-128-3
dimension 5560*1370*1780mm
quiantity of needle bar 3
quilting width 3300mm
space between needle bars 76.2, 152.6mm
space between needle 25.4mm
thickness of quilting  30mm
stitch length  2-7mm
model of needle 14-21#
total power required 4.0kw
main shaft speed  300-800rpm
gross weight 3800kg





Application :



360 Patterns Digital Multi Needle Quilting Machine 3800kg 3 Phase 0   360 Patterns Digital Multi Needle Quilting Machine 3800kg 3 Phase 1





360 Patterns Digital Multi Needle Quilting Machine 3800kg 3 Phase 2   360 Patterns Digital Multi Needle Quilting Machine 3800kg 3 Phase 3
